ENVE Composites

ENVE AR Disc Fork

ENVE AR Disc Fork

Hub Spacing
$800.00 CAD
$800.00 CAD
Sale Inquire for Availability
Shipping calculated at checkout.

The ENVE All Road Fork is not just a repurposed cyclocross fork or simply a carbon fiber road fork with increased tire clearance; it is a fork built from the ground up to specifically service the gravel and all-road markets. Axle to crown length and fork rake were carefully chosen for the intended use.

More and more, cyclists are venturing off the beaten path on drop-bar bikes for both adventure and racing. Our goal was to create a fork using the same one-piece, 100% uni-directional carbon fiber construction found on all ENVE forks, and add unique design elements that would be beneficial in the burgeoning gravel and all-road scene.

The ENVE All Road Fork (AR) is loaded with unique features like an industry-first optional integrated yet removable fender, disc brake hose clip, and 12mm thru-axle for superior braking and steering performance.

  • 1-1/8 to 1-1/4 tapered steerer tube.
  • 12mm thru-axle dropout.
  • Optional carbon fiber fender that keeps mud and water off you and your bike - the full carbon fender can be installed or removed in seconds.(Sold Separate)
  • Flat Mount Brake calipers come standard, and will work with 140 and 160mm (with adapter) rotors.
    Material Carbon Fiber
    Steerer Tube Length 400mm
    Steerer Tube Taper 1.125″ to 1.25″
    Rake 47
    Axle to Crown 382mm
    Brake Disc
    Axle Compatibility 12mm
    Max Rotor Size 160mm
    Max Tire Clearance 35mm w/ fender, 38mm w/o fender
    Torque Spec: Steer 5.5Nm
    Torque Spec: Axle 8Nm
    Fork Weight 450g
    Fender Weight 150g
